Translucent Epoxy Casting Resoltech

Epoxy resin of the brands Resoltech
Offered in 2 versions,
Epoxy Kit WWA 1.4Kg and 7Kg or Epoxy Kit 4000 1.38L

Express delivery.

Our photoluminescent, pearlescent or liquid pigments are compatible with our epoxy resins

Reduced price!
48.43£ tax incl.

49.42£ tax incl.

(price reduced by 2 %)

DS 4000 DS WWA PRICELIST RESINS - APPLICATORS
Versions

Epoxy resin for casting or glazing


We offer 2 types of high performance and solvent free filling / casting resins:


- WWA epoxy resin (for work from 3 to 16cm * max thickness - slow drying) mix 100 - 40



- 4000 epoxy resin (for work from 0.5 to 4cm * thick max- fast drying) 100 - 38 mix



* for a cylinder or cube volume (width = height)


Version to choose from the drop-down menu



Main Features


Resins of professional use, very hard, or flexible according to dosage, highly translucent, good resistance to UVs.
Download the technical sheet at the bottom of the page.



Density of WWA / Hardener mixture: 1.06
Or 1 Liter = 1.06 kg


1- Translucent Epoxy casting resin for molding / filling WWA


Offer: 1.4 kg kit including epoxy resin + hardener
            kit 7 kg including epoxy resin + hardener

WWA resin is part of the Epoxy family (0% solvents) and guarantees the best results for casting and filling work, without thickness limit, for technical, industrial or decorative applications (art, sculpture, furniture) .

The WWA system is made without solvent / no toxics.

The product is perfectly translucent and allows the mixing of pigments by allowing light and color to penetrate and exit.

Our resin is perfectly compatible with many raw materials (glass, wood, concrete, stone, terracotta, metals ...) and allows for all kinds of artistic work.
It is with the resin WWA that one can make deep colors on wood, for example to realize epoxy river tables




Withdrawal :
Unlike polyester, polyurethane and others, our resin does not move, crack or shrink on drying.
After drying, it gives a shiny, transparent and hard object.

RESOLTECH WWA molding resin is the least viscous product (easy to use) that allows you to work without limit of thickness (unlimited possibility).
It contains a debulling additive that avoids as much as possible the formation and imprisonment of air bubbles.

The flexibility of the resin is possible by modifying its mixing ratio:

HARD version:
WWA Resin WWB4 Hardener
By volume: 2 1
in weight: 100 40

FLEXIBLE variant:
WWA Resin WWB4 Hardener
By volume: 1 1
in weight: 100 89

It is important to have a perfect and precise mix.


Drying and hardening of the resin

Life of the pot mixture: 10h Curing time: 19h

Usage tips :
- the ideal temperature is 20 to 25 ° C (better hardening and debulking)
Warning, the hotter it is, the hardening is done quickly and inversely.
And the warmer it is, the more liquid it is.

Also, be aware that the greater the thickness, the faster the product heats and hardens
In addition, the use of a large mass tends to accelerate hardening.

The mixture is very important. Most defects are caused by a bad mixture.
Weigh carefully, and stir with insistence. Apply the product after a time of 5 to 10 minutes

Consult the technical sheet pdf attached to the product page in red


2 - Epoxy resin 4000 for glaze, varnishing and casting in thickness of 1cm max.

This is a quick version of the epoxy resin, so with a quick drying, but also the ability to varnish with a very beautiful level of gloss, brush, with an exceptional thickness, and self-leveling.
Ideal use on wood (furniture and tables), carbon fibers (surf, fairings ..)
Compatible with all our pearlescent pigments, or our dyes.


Calculation of the need:


Knowing that the liquid volume = the volume hardened and dry

(because no evaporation of solvent)

the volume yield is calculated as follows:

1.4 liters = 1.4m² x 1mm thick is 1.4dm3



Mix of Pigments



To mix pigments, prefer stirring.

With phosphorescent pigments, prefer gentle stirring, because the micro crystals can "cut the bonds of the resins" if one agitates too much.



For the mixing of phosphorescent pigments, use our Solvented pigments for Epoxy resins. They offer a greater choice of colors, and are available in smaller sizes (they diffuse light better than large pigments, and are lighter, so they sediment less)


Some tips:

- If you work in very thick, even if you can make a casting of 15 cm deep at one time, you can also do a filling in 2 or 3 times, leaving completely dry between each application, because the resin shrinks slightly during drying. We can sand the surplus, or pass a scotch tape brite between layers to create adhesion between layers.

Begin by brushing the interiors and then other layers after the first coat is completely dry.

- The more you work in thickness, the less you have to load in pigments.

- The recommended pigment load should be 15% maximum, to avoid cracking. In large thickness, a load of 5% is sufficient.

- Slow drying at room temperature is recommended.

- Final sanding should be done only when the resin is completely dry to the core



Epaisseur/Thickness < 0.5cm => Pigments = 5-20%

Epaisseur/Thickness < 1-2cm => Pigments = 3-10%

Epaisseur/Thickness 2-10cm => Pigments = 2-5%





WWA and 4000 SAFETY INSTRUCTIONS


Strong reactions may occur


WWA
If the casting thickness exceeds the maximum indicated, overheating, smoke release, etc. may occur.

We recommend that you carefully read the technical data sheet at the bottom of the page regarding thickness and mass effect.

> Maximum thicknesses are specified for shapes where depth = diameter
 an example cylinder: 15 cm deep x 15 cm in diameter

Case of a superior casting:
For the realization of a river table, it is advised not to exceed 2 cm of thickness, and to renew the operation until the ostension of the desired thickness.
To overcome a problem of curvature, it is necessary that the flows are of the same thickness (example 2cm / 2cm)



4000
If the casting thickness exceeds the maximum indicated, overheating, smoke release, etc. may occur.

We recommend that you read the technical data sheet at the bottom of the page regarding thickness and mass effect, the 4000 resin being very reactive.

> Maximum thicknesses are specified for a cylinder or cube 4cm deep and 4cm in diameter

Case of a superior casting:
When making a varnish or a glaze on a river table the width of the casting will be much higher (example: 100cm).
In this case, we recommend that you proceed in several flows not exceeding 0.2 - 1cm thick.



Question:

I do not understand What are these numbers?

For 100 ml of resin to be cast how much resin must be put in it? Hardener? Should we add water?


Reply :

The mixture is by weight (kilograms or grams - Kg or g) or by volume (Liters or milliliters - L or ml)

for example :

By volume: 2 1 means 200 ml of resin + 100 ml of hardener

in weight: 100 40 means 100g of resin + 40g of hardener

There are no other ingredients to add.

the mixture must be made extremely accurately with a scale (by weight) or a measuring cup (by volume)
